Elitech ILD-200 Electronic Refrigerant Leak Detector HVAC, Freon Leak Detector, Infrared Sensor up to 10 years' service life, 4g/yr, PEAK Record
Elitech ILD-200 with leak detector for all common refrigerants CFC, HFC, HCFC, PFC, and HFO, includes leak detector, UV light, charging cable, replacement filters, and carrying case. The infrared sensor features a long service life of over 10- years, undegradable sensitivity, and limiting false alarms, which is the best sensor in the leak detection system. Moreover, with exclusive ergonomic design, peak value record and innovative large TFT LCD screen, the detector optimizes the user experience and presents the detection results more intuitively and diversely. With ILD-200, you will ideally equip to carry out quick, reliable leakage detection.
Elitech ILD-200 Parameter
|Sensor Sensibility||Max. 4g/year|
|Sensor Life||10 years|
|Detectable Gases||R134a, R410A, R32, R22, HFO-1234 and all HFCs, HCFCs, CFCs, PFCs.|
|Auto OFF||After 10min of inactivity|
|Power||Built-in lithium battery 3.7V 3000mA|
|Battery Runtime||Up to 6 hours ccontinuously|
|Charging Time||Within 4hrs|
|Storage Temperature||-20°C~ 60°C (-4°F~ 140°F)|
|Operating Environment||Temperature: -10°C~ 52°C (-4°F~ 140°F) Humidity: 50%~85% RH|
|Alarm Mode||Audible and Visual|
|Tool Size||95*45*190mm (3.75*1.76*7.50in.)|
|Tool Weight||415g (14.6oz)|
|Certification||CE, SAE_J1627, SAE_J1791, SAE_J2913, EN14624:2012|
Elitech ILD-200 Features
- Premium Infrared Sensor* This refrigerant leak detector adopts a premium infrared sensor that has a long service life of over 10 years and its sensitivity won't degrade over time, making it the very best air conditioning leak detection tool.
- Precise and High Sensitivity* The freon leak detector has a maximum sensitivity of 4g/yr, which enables the detection of even the smallest leaks. Sensitivity can also be adjusted in three different levels to pinpoint leakage quickly and precisely.
- Large TFT LCD Screen* Very rarely in the industry, Elitech ILD-100 is equipped with a 2.8in. TFT LCD screen, to show real-time gas leakage concentration, sensitivity level, power, buzzer status, and false alarm. You can know everything about the detector in one glance.
- Rechargeable Lithium-ion Battery* Built-in 3.7V 3000mA lithium-ion battery can work continuously for 6 hours upon one full charge. USB charging cable is included in the package for easy recharging through the Type C port.
- An All-rounder in Leak Detection* Elitech ILD-100 is a fast,reliable leak detector for all common refrigerants, including R134a, R410A, R32, R22, HFO-1234 and all HFCs, HCFCs, CFCs, PFCs.
An All-Rounder in Leak Detection*
Detect all common refrigerants including R134a, R410A, R32, R22, HFO-1234 and all HFCs, HCFCs, CFCs, PFCs
Large TFT LCD Screen*
Everything about the detector and task can be viewed easily just in one glance
Sensitivity can be adjusted in three different levels: High, Medium and Low, to pinpoint leakage quickly and precisely
Rechargeable Lithium-ion Battery*
Built-in 3.7V 3000mA lithium-ion battery can work continuously for 6 hours upon one full charge
Earplug connection for safe leakage detection in loud environments
Elitech ILD-200 Package
- 1 x ILD-200 infrared leak detector
- 1 x UV light
- 1 x USB charging cable
- 10 x replacement filters
- 1 x sturdy carrying case
Elitech ILD-200 Related Documents
- Elitech ILD-200 Refrigerant Leak Detector User Manual
- Elitech ILD-200 Refrigerant Leak Detector CE Certification
Elitech Infrared Refrigerant Leak Detector Comparison
Detector de fugas de gases refrigerantes halogenados. Como funciona por IR, apenas da falsos positivos y es suficientemente sensible para uso profesional, que es mi caso. Inferior en solidez a otros modelos profesionales, pero por una fracción del coste de aquéllos. La célula IR parece más duradera que en otros mucho más caros. El tiempo dirá si es buena compra, aunque por ahora lo parece.
Working great for R134a, R410a, R12 and R22
Very effective product as I tried to hunt down a leak in the A/C system in my car. It actually has 3 models and the first is really sensitive as I have to turn it down a bit. Not sure about the other ones, but it did really a perfect job on detecting R134a, R410a, R12 and R22. My favorite part about this device is the visual indicator as well as the tone which makes it extremly easy to use.
Really good quality. Very happy with the product. Thanks
